Print |
printing method |
Thermal printing |
Resolution |
203 DPI |
printing speed |
70mm/s |
Print width |
72mm |
Print length |
1778 mm
|
CPU |
32-bit processor |
RAM |
Memory |
8MB Flash Menmory/8MB SDRAM |
Communication Interface |
Communication Interface |
USB2.0 + Bluetooth / WIFI (optional) |
Power Specifications |
Power Specifications |
Adapter input: AC 100-240V, 0.5A, 50-60Hz Output: DC 5V/2A
battery: 7.4V/2500mAh |
User Interface |
Operation switch, button |
Standard model with
3 physical buttons, OLED (0.96″) display (128*64 resolution) |
sensor |
sensor |
Gap sensor/open cover sensor/black mark sensor |
Built-in fonts |
Built-in fonts |
Eight bitmap fonts/Windows fonts can be downloaded through software for use |
Barcode character graphics |
Bar code |
1D bar code: Code 39, Code 93, Code 128UCC, Code 128 subsets A, B, C,
Codabar, Interleaved 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN
and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST |
QR code |
2D bar code: PDF-417, Maxicode, DataMatrix, QR code |
Font and barcode rotation |
0°, 90°, 180°, 270° |
Printer language |
Printer language |
TSPL, EPL, ZPL, DPL, CPCL, ESC/POS |
medium |
Media type |
Continuous paper, gap paper, black mark paper |
Media width |
25.4 mm ~ 76 mm |
Media thickness |
0.06 mm ~0.254 mm |
Accessories |
Accessories |
Power cord (adapter); USB transmission line |
Factory option |
Factory option |
①WIFI |
safety certificate |
safety certificate |
FCC, CE, CCC, CB |
Physical characteristics |
weight |
0.4kg (including battery) |
physical dimension |
120(D) x 112(W) x 60(H)mm |
Environmental requirements |
working environment |
-10 ~ 50°C, humidity (non-condensing) 25 ~ 85% |
Storage environment |
-40 ~ 60°C, humidity (non-condensing) 10 ~ 90% |
reliability |
reliability |
Printer one year/print head 30km or first arrival in a year/rubber 30km or first arrival in a year |
